Figaro
High Definition Music Player

Figaro streamer has the same digital platform of R8, simplifying the less commonly used port and function while providing a much cheaper price and higher value for our users.

Figaro puts more focus on playing DSD music and supports DSD128files. We choose the only chip which allows the DSD data to stream directly.

RESOURCES
DOWNLOAD



OPTIONAL ADAPTORS


The X1, X2 and X3 are the optional adaptors for the Figaro.

X1
X2
X3
The X1 is a DVD-ROM and removable HDD intergrated adaptor. The power supply is linear transformer design.

The DVD-ROM USB-type B wire input to the Figaro USB 1.1 port acts as a CD player. The Figaro has the optimized algorithm to read CD's. The laser head captures the CD data and places it into the cache. While doing this the Figaro operates the error correction function. The laser head will read the content several times to check and correct any errors. So the CD sounds better than a traditional CD player, even the top-level Philips CD-PRO2M.

The removable HDD adaptor supports 3.5 inch SATA hard drives. The HDD is very easy to install in the X1 - Simply open the front panel and insert the HDD. The X1 supports HDD's with the capacity of up to 4TB's.


The X2 is a V3.0 Blue-tooth adaptor. The X2 supports APTX to transmit 16bit/44.1kHz CD quality S/PDIF streams. The power supply comes through the USB port. The output terminal is a coaxial RCA port.


The X3 is a TP-link with the pre-installed client mode and bridged function.
After connection with the router by WI-FI, the cell phone and PAD can remotely control the player.
Without drives or any software the X3 can be used directly. Simply press the WPS key to connect the main router, after that, nothing more.


The X3 supports one-button (WPS) operation. When connect to your rooms WIFI router the Consonance stream player plays through the X3 repeater link to the WIFI network for DLNA function. Only during first time connection does the user need to perform this WPS operation. The X3 repeater will connect to the WIFI network automatically when turned on.

DLNA MODE

We designed a new DLNA mode to help the Reference8 to sound better and be more efficent.
Control support is through any computer, Google Android smartphones or other digital control devices.
The Reference8 control support can be performed by iOS APP 8players (for ipad/iphone), and BubbleuPnP (for Android).

  8player
for iOS (suggest pay for official version)
    BubbleuPnP
for Android

NETWORK

It has a high quality built in internet radio receiver. Through radio firmware upgrades it will be able to get more radio stations.


Specifications:
3 inch TFT nature color full screen, support IR remote control, iphone and Android phone/pad control
Internet radio
Upgradeable firmware through USB memory device
USB2.0 port x 2 for  hard disk up to 4TB, eSATA power port, USB1.1 port for external CD-ROM
Streaming protocol

UPnP AV protocol with audio streaming extension
Gapless Playback
On-device Playlist

Music Format

DSD: DSF (DSD), DIFF (DSD)
PCM: FLAC, Apple Lossless (ALAC), WAV, AIFF, APE
AUDIO: MP3, AAC

Supported Frequencies

PCM, 44.1kHz -384kHz, 16-32bit, Stereo
DSD, 2.8MHz, 5.6MHz, 1bit, Stereo

Inputs
Ethernet, USB 2.0, USB1.0, digital SPDIF
Outputs

Analogue outputs:
XLR balanced, 2.5Vrms
RCA unblanced, 2.5Vrms

Digital output:
SPDIF:
PCM 44.1khz-192kHz, 16-24bit

Analogue output:2.3V RMS (RCA,XLR)
Harmonic distortion:less than 0.0025%(XLR), 0.003%(RCA)

Signal to noise :better than 110dB(RCA,XLR)
