Digital System

CDS120 Music player
Music player

Music Streamer

CD player




CDS120 is designed to sit in the heart of your audio system. Use as a streamer, a DAC, a CD player or all three!

Main features
CDS120 makes system integration easier than ever:
CD playback adopts high-stability in-vehicle slot-in mechanism for reading, buffering and processing by decoding chip
3 digital inputs
USB Digital Audio input & output support up to Native DSD512
Balanced & unbalanced analogue outputs
SPDIF & Optical input support up to 192/24
The processor can be connected to the Xmos decoding part through the USB interface
supporting DLNA, ROON Ready and Spotify Connect, Bluetooth and Tidal, Qobuz and many more

Specified for exceptional musical performance:
Processor delivers native DSD512 & PCM768 playback
The analog output uses a unique DC Class A analog filter, and a discrete component amplifier module is used to replace the usual operational amplifier, making the sound more transparent and musical
Femto Clock System
Integrated dual-toroidal linear power supply & all-in-one chassis


Specifications

Supported audio file formats:
DSD: DSF (DSD), DIFF (DSD)
PCM: FLAC, Apple Lossless (ALAC), WAV, AIFF, MP3, AAC

Supported audio sample rates, bit depths, number of channels:
PCM, 44.1KHz-768KHz, 16-32bit, Stereo DSD, 2.8MHz-22.4MHz, 1bit, Stereo

LAN: Gigabit
Digital inputs: USB2.0, USB, Coaxial, Optical, Bluetooth (Name: Opera)
Digital outputs: USB2.0, CD Coaxial output
Analog outputs: XLR balanced, 4.8Vrms, RCA unbalanced, 2.4Vrms,
Distortion: <0.0025%
Signal-to-noise ratio: >110dB (RCA, XLR)
Dimensions: 12cm43cm36cm (HWD)
Weight: 9.5kg


RESOURCES
Owner's Manual
Control app for Android system (Right-click the link and save)
